The DAF is an industrial high-power forestry brushcutting-mulching system that can be installed on most compact loaders or other dedicated forestry carriers. DAF brushcutters and mulchers are designed for vegetation control work.
Specifications & Details
| SPECIFICATION | DAF-250Ex | DAF-225Ex | DAF-225E | DAF-180E | DAF-180D | DAF-150D |
| Approximate Min. Carrier Power |
250 HP (190 kW) | 200 HP (150 kW) | 175 HP (130 kW) | 125 HP (95 kW) | 85 HP (65 kW) | 75 HP (60 kW) |
| Cutting Width | 99" (251 cm) | 85" (216 cm) | 88" (223cm) | 74" (188 cm) | 74" (188 cm) | 59" (150 cm) |
| Cutting Distance from Ground Level |
.4" (1 cm) | .4" (1 cm) | .4" (1 cm) | .8" (2 cm) | .8" (2 cm) | .8" (2 cm) |
| Number of Blades on Rotor | 35 | 31 | 31 | 27 | 27 | 21 |
| Optimal Target Material Diameter |
24" (61 cm) | 24" (61 cm) | 15" (38 cm) | 10" (25 cm) | 8" (20 cm) | 6" (15 cm) |
| Exterior Width | 103" (261 cm) | 102" (259 cm) | 100" (254 cm) | 88" (223 cm) | 87" (221 cm) | 72" (183 cm) |
| Exterior Height (with Pushbar) | 61" (155 cm) | 58" (147 cm) | 55" (140 cm) | 55" (139 cm) | 58" (147 cm) | 59" (150 cm) |
| Exterior Height (without Pushbar) |
38" (97 cm) | 38" (97 cm) | 38" (97 cm) | 37" (94 cm) | 44" (112 cm) | 26" (66 cm) |
| Exterior Depth (with Pushbar) | 50" (127 cm) | 51" (130 cm) | 55" (140 cm) | 45" (114 cm) | 51" (130 cm) | 48" (122 cm) |
| Exterior Depth (without Pushbar) |
33" (84 cm) | 33" (84 cm) | 33" (84 cm) | 27" (69 cm) | 31" (79 cm) | 29" (74 cm) |
| Rotor Diameter | 20" (51 cm) | 20" (51 cm) | 20" (51 cm) | 20" (51 cm) | 18" (46 cm) | 18" (46 cm) |
| Weight, typical (estimated) | 5400 lb (2449 kg) | 5200 lb (2359 kg) | 4700 lb (2132 kg) | 3300 lb (1497 kg) | 3200 lb (1452 kg) | 2300 lb (1043 kg) |
| HYDRAULIC SYSTEM | DAF-250Ex | DAF-225Ex | DAF-225E | DAF-180E | DAF-180D | DAF-150D |
| Variable Displacement Axial Piston Motor |
2 | 2 | 1 | 1 | 1 | 1 |
| Max. Cyl. | 115 | 115 | 170 | 170 | 115 | 85 |
| Max. Motor Torque (T max at Vg max), lbs-ft |
502 | 502 | 907 | 502 | 502 | 450 |
| Nm | 681 | 681 | 1230 | 681 | 681 | 610 |
| Required Continuous Flow* | 80 gal/min (303 L/min) |
75 gal/min (284 L/min) |
60 gal/min (227 L/min) |
50 gal/min (189 L/min) |
35 gal/min (132 L/min) |
23 gal/min (87 L/min) |
| Operating Pressure* | 6000 psi (414 bar) | 6000 psi (414 bar) | 6000 psi (414 bar) | 6000 psi (414 bar) | 5000 psi (345bar) | 5000 psi (345bar) |
| Rotating Speed | 2250 r/min | 2250 r/min | 2350 r/min | 2400 r/min | 2550 r/min | 2600 r/min |
| Pressure Line I.D. | 1.25" (#20) | 1.25" (#20) | 1" (#16) | 1" (#16) | 1" (#16) | .75" (#12) |
| Return Line I.D. | 1.25" (#20) | 1.25" (#20) | 1" (#16) | 1" (#16) | 1" (#16) | .75" (#12) |
| Drain Line | 1" (#16) | 1" (#16) | .75" (#12) | .675" (#10) | .675" (#10) | .625" (#10) |
| FEATURES | DAF-250Ex | DAF-225Ex | DAF-225E | DAF-180E | DAF-180D | DAF-150D |
| Sharpenable Bolt-on Forged Blades |
Standard | Standard | Standard | Standard | Standard | Standard |
| Hydraulic Pushbar | X | X | X | X | X | X |
| Bolt-in Wear Liner | X | X | X | X | X | |
| *These are minimum requirements; call your Denis Cimaf Sales Representative for guidance in selecting the best match for your equipment. |
What is a front-mounted mulching attachment, and how does it work on a skid-steer?
A front-mounted mulching attachment, such as Denis Cimaf, is designed to be mounted on the front of a skid-steer. It uses a robust cutting mechanism to shred vegetation into fine mulch, ideal for land clearing and vegetation management tasks.
What types of skid-steers are compatible with Denis Cimaf attachments?
Denis Cimaf mulching attachments are typically compatible with a wide range of skid-steer models. It's important to check specifications and ensure compatibility with your specific skid-steer model.
What are the advantages of using a front-mounted mulching attachment on a skid-steer?
Front-mounted attachments like Denis Cimaf provide several advantages, including increased maneuverability, enhanced visibility for the operator, and the ability to work in tight spaces where larger equipment may not be suitable.
How does a front-mounted mulcher affect the performance and handling of a skid-steer?
When properly balanced and installed, Denis Cimaf attachments integrate seamlessly with the skid-steer, maintaining the machine's stability and agility while significantly boosting its land-clearing capabilities.
What kind of maintenance is required for Denis Cimaf attachments on skid-steers?
Regular maintenance such as checking hydraulic connections, inspecting cutting teeth for wear, and greasing bearings is recommended to ensure optimal performance and longevity of the attachment.
Can Denis Cimaf attachments handle different types of terrain and vegetation?
Yes, Denis Cimaf attachments are designed to handle various terrains and dense vegetation types efficiently. They are versatile tools suitable for both forestry and land management applications.
Are there specific safety considerations when using Denis Cimaf attachments on skid-steers?
Operators should follow safety guidelines and wear appropriate personal protective equipment (PPE). It's crucial to maintain awareness of surroundings, especially when operating in areas with uneven terrain or obstacles.
What are the typical applications for front-mounted mulching attachments like Denis Cimaf?
Denis Cimaf attachments are commonly used for tasks such as land clearing, right-of-way maintenance, trail and roadside vegetation management, and environmental restoration projects.
How does the mulching quality compare with other methods of vegetation control?
Denis Cimaf mulching attachments produce fine mulch that aids in soil health and erosion control, offering a more environmentally friendly alternative to traditional land-clearing methods.
Is training required to operate a skid-steer with a Denis Cimaf attachment?
While specific training requirements may vary, operators should have a good understanding of skid-steer operation and safety protocols. Familiarity with the attachment's controls and maintenance procedures is also beneficial.
